High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing

1
MOQ
$210.23-230.51
preço
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Tipo: Adaptador e conectores de fibra
Material: Aço inoxidável endurecido s136
Dimensões: 174 mm x 174 mm x 5,1 mm
Peso: 1,2 kg
No. de fibra: 24
Diâmetro da fábrica: 2,5 mm
Capacidade: 24 posições
Perda de inserção: ≤0.20dB
Perda de retorno: ≥55dB (PC)
Fim-cara: PC
Tipo de conector: PC DE FC
Modelo: FC-PC-24
Peso líquido: 1,5 quilogramas
Peso bruto: 2,0 QUILOGRAMAS
Máquinas adequadas: Máquina de polimento CLX-02E, máquina de polimento Seikoh Giken SFP-550
Destacar:

High Efficiency Polishing Fixture

,

Anti-Rust Fiber Optic Polishing Jig

,

Durable Fiber Polishing Fixture
Informação básica
Lugar de origem: Guangdong, China
Marca: chuanglixun
Número do modelo: FC UPC-24, FC UPC-24
Condições de Pagamento e Envio
Descrição de produto
24 Port FC UPC Fiber Optic Polishing Jig
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 0
This fiber polishing fixture/jig offers high stability and excellent surface quality. Constructed with high-quality heat-treated steel (hardened steel S2316) for extended service life. The fixture can be designed for SC, FC, ST, LC connectors and customized to customer requirements.
Key Features:
  1. Designed specifically for FC/PC connectors
  2. Easy jig changing with simple, flexible operation
  3. High efficiency - polishes up to 24, 32, or 36 connectors per cycle with 98-100% first-pass yield
  4. IPC structure with independent compression for each connector
  5. Exceptional performance: PC return loss ≥55dB, insertion loss ≤0.20dB (typical)
  6. Replaceable accessories significantly extend service life
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 1 High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 2 High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 3
Technical Specifications:
Model FC-PC-24 FC-PC-32 FC-PC-36
Brand CLX CLX CLX
Connector Type FC PC FC PC FC PC
End-face PC PC PC
Ferrule Diameter 2.5mm 2.5mm 2.5mm
Capacity 24 positions 32 positions 36 positions
Insertion Loss ≤0.20dB ≤0.20dB ≤0.20dB
Return Loss ≥55dB (PC) ≥55dB (PC) ≥55dB (PC)
Application Polishing assembled FC PC connectors
Material Stainless Steel
Dimension (L*W*H) 174*174*26 mm
Net Weight / Gross Weight 1.5 kgs / 2.0 kgs
Compatible Machines CLX-02E polishing machine, Seikoh Giken SFP-550 polishing machine, and similar models
Polishing Performance:
1. Polished Connector Ferrule Faces:
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 4
High-quality end-face polishing with no white spots or scratches, clearly visible fiber edges.
2. ILRL Test Results:
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 5
Connector Type SM/UPC SM/APC MM/UPC
Insertion Loss ≤0.20dB ≤0.20dB ≤0.50dB
Return loss ≥55dB ≥60dB ≥30dB
3. Geometry Test Results:
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 6
Parameter UPC Criterion APC Criterion
Radius of Curvature 5-25mm 5-12mm
Apex Offset 0-50μm 0-50μm
Fiber Height -100~+50μm -100~+50μm
Angle n/a 8.00+/-0.50°
Manufacturer Information
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 7
Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd.
Established in 2010, we are an optical communications equipment company specializing in R&D, production, after-sales service and technical support. We provide high-quality products along with comprehensive technical solutions for fiber optic connector production challenges.
High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 8 High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 9 High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing 10
Frequently Asked Questions
1. Are you a factory or a trader?
We are the manufacturer.
2. What is your MOQ?
Minimum order quantity is 1 piece.
3. Do you provide sample services?
Yes, we provide samples.
4. How will you ship to me?
Standard shipping via DHL or FedEx takes 4-6 days. Larger orders may require additional time.
5. How do we pay?
We accept advance booking or multiple payment methods including T/T and T/L.
6. How long is your product warranty?
1-year warranty covering free repairs (excluding consumables). After warranty, we provide cost-based replacement parts.
7. Do you provide customized services?
Yes, we offer customization based on customer requirements.
